Best 12v 200ah Solar Battery Storage System Deep Cycle Solar Panel GEL Battery

FUZHOU THINMAX SOLAR CO., LTD
Contact Now

Best 12v 200ah Solar Battery Storage System Deep Cycle Solar Panel GEL Battery

Brand Name : Thinmax

Certification : ce

Model Number : 12v

Place of Origin : Guangdong, China

Packaging Details : One piece per carton.

Supply Ability : 100 Piece/Pieces per Week

MOQ : 5 pieces

Price : $298.00/pieces 5-9 pieces

Weight : 164kg

The charging ratio : 15khw

The discharge rate : 15kwh

Warranty : 1 year

Anode Material : LFP

Chargeable : Yes

Application : Solar Energy Storage Systems

Contact Now

Best 12v 200ah Solar Battery Storage System Deep Cycle Solar Panel GEL Battery



Product Description
Best 12v 200ah Solar Battery Storage System Deep Cycle Solar Panel GEL Battery

Product Parameters

Rated voltage Capacity (10hr, 1.80V/Cell) Max discharge current Max charging current Self-discharge (25ºC) Recommended Using temperature Cover Material
12V 200AH 30I10A (3min) ≤0.25C10 ≤3%/ month 15ºC~25ºC ABS

Using temperature Charging Voltage (25ºC) Charging Mode (25ºC) Cycle life Capacity Affected by Temperature
Discharge: -45ºC~50ºC
Charge: -20ºC~45ºC
Storage: -30ºC~40ºC
floating charge: 13.5V-13.8V
equalizing charge: 14.4V-14.7V
Float Charge: 2.275±0.025V/Cell
Temperature parameters: ±3mV/CellºC
Cycle Charge: 2.45±0.05V/Cell
Temperature Compensation Coefficient
±5mV/Cell ºC
100% DOD 572 times
50% DOD 1422 times
30% DOD 2218 times
105% @ 40ºC
90% @ 0ºC
70% @ -20ºC

Termitation Voltage (V/Cell) 1H 2H 3H 5H 10H 20H 50H 100H 120H 240H
1.7 106.2 48.28 32.27 32.27 20.81 10.75 4.52 2.45 2.17 1.15
1.75 104.08 47.79 31.69 31.69 20.52 10.5 4.35 2.29 2.03 1.07
1.8 102 47.33 31.2 31.2 20 10.25 4.2 2.2 1.89 1.01
1.85 97.92 47.07 30.6 30.6 19.17 9.75 4.03 2.05 1.77 0.92
1.9 94.01 46.65 30.15 30.15 18.77 9.58 3.91 1.99 1.69 0.87
1.95 89.88 45.72 45.72 29.52 17.73 8.92 3.63 1.88 1.61 0.83






Advantages of colloidal solar cells



1. The real green power



The battery plate material is made of special alloy, which does not contain antimony, cadmium and other substances harmful to the environment. And the battery also uses a special nanomaterial gel, so even if the cover is broken, it will not splash acid.



2. Low internal resistance



The use of imported low internal resistance separators and special technology makes the colloidal battery have the advantages of low internal resistance, good battery capacity, and high discharge efficiency.



3. Low self-discharge rate



Less than 3% per month, lead-acid is less than 15% according to Chinese battery standards.



4. Low gas production rate



The outgassing rate of gel batteries is only 5% of ordinary sealed batteries.



5. Long life design



The lifespan is more than 1000 times at 25 ºC, the average battery is only 600 times according to the industry standard. Lifespan will vary widely based on usage, maintenance and charging, temperature, and other factors. But usually it is 5-8 years.



6. Wider temperature range



-30ºC to 55ºC, suitable for different temperature and charging and discharging conditions



7. Excellent discharge recovery ability



When the battery is discharged to close to 0V, short-circuit the two poles of the battery for 24 hours, fully charge it again, and run it 5 times. 90% of the initial capacity can be released when the battery is discharged to 10.5V each time.



Best 12v 200ah Solar Battery Storage System Deep Cycle Solar Panel GEL Battery

Best 12v 200ah Solar Battery Storage System Deep Cycle Solar Panel GEL BatteryBest 12v 200ah Solar Battery Storage System Deep Cycle Solar Panel GEL BatteryBest 12v 200ah Solar Battery Storage System Deep Cycle Solar Panel GEL Battery

Packing & Delivery
Best 12v 200ah Solar Battery Storage System Deep Cycle Solar Panel GEL Battery
Best 12v 200ah Solar Battery Storage System Deep Cycle Solar Panel GEL Battery
Best 12v 200ah Solar Battery Storage System Deep Cycle Solar Panel GEL Battery
To better ensure the safety of your goods, professional, environmentally friendly, convenient and efficient packaging services will be provided.


Company Profile
Best 12v 200ah Solar Battery Storage System Deep Cycle Solar Panel GEL Battery
Best 12v 200ah Solar Battery Storage System Deep Cycle Solar Panel GEL Battery
Best 12v 200ah Solar Battery Storage System Deep Cycle Solar Panel GEL Battery


Why Choose Us
Best 12v 200ah Solar Battery Storage System Deep Cycle Solar Panel GEL BatteryBest 12v 200ah Solar Battery Storage System Deep Cycle Solar Panel GEL Battery

Fuzhou Thinmax is a solar company located at the city Fuzhou which is the capital of Fujian province. We have about 50 office colleagues and 100 factory colleagues. With the professional colleagues and over 10 years experience of dealing with solar system, we are able to provide 100% satisfying service for customers. Not only for the ready products but also the customized products. In order to make the ship more fluently. We have cooperated with more than 20 shipping companies. After customers place the order. We will always choose the cheapest and reliable one to arrange the shipment. When customers have received the items. We have professional technician ready for customers if they have any problems. Please trust Thinmax and give us an opportunity to provide service for you. We won't let you down.


FAQ

1. who are we?
We are based in Fujian, China, start from 2021,sell to Western Europe(50.00%),Eastern Europe(10.00%),South Asia(5.00%),Southern Europe(5.00%),Northern Europe(5.00%),Eastern Asia(5.00%),Southeast Asia(5.00%),Mid East(5.00%),Oceania(5.00%),Africa(5.00%). There are total about 11-50 people in our office.

2. how can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;

3.what can you buy from us?
Solar inverter,Solar panel,Solar system,Battery,Wind system

4. why should you buy from us not from other suppliers?
With more than 10 years experience of dealing with solar system. We provide high quality pre-sale and after-sale service for our customers. We also have factory and professional technicians so we can provide customized product services for customers too.

5. what services can we provide?
Accepted Delivery Terms: FOB,CFR,CIF,EXW,DDP,DDU;
Accepted Payment Currency:USD,EUR,AUD,CNY;
Accepted Payment Type: T/T,MoneyGram,Credit Card,PayPal,Western Union,Cash;
Language Spoken:English,Chinese
